SAMSUNG 9100 PRO M.2 2280 PCIe GEN5X4 NVMe SSD With Heatsink (R:14,800 MB/s W:13,400 MB/s) - 4TB

Key Features:

• Capacity : 4,000GB (4TB)
• Form Factor : M.2 (2280)
• Interface : PCIe® 5.0 x4, NVMe™ 2.0
• Sequential Read
• Up to 14,800 MB/s * Performance may vary based on system hardware & configuration
• Sequential Write
• Up to 13,400 MB/s * Performance may vary based on system hardware & configuration

Performance ready for a new era

Blazing speed. Massive capacity. Built for AI and beyond. With up to twice the speed of the 990 PRO SSD and up to an 8TB storage option, the Samsung 9100 PRO with Heatsink SSD supercharges AI workloads, 4K video rendering, and gaming.

Kick your gameplay into overdrive
Unleash peak performance with blazing fast 9100 PRO SSD with Heatsink, built for AI and beyond.

Breakthrough PCIe® 5.0 performance
PCIe® 5.0 Performance
Supercharge your workflow and gaming with lightning-fast PCIe® 5.0, boasting sequential read/write speeds up to 14,800/13,400 MB/s. Effortlessly tackle the heaviest files, from massive video projects to hi-res image editing. Experience the jaw-dropping speed of Gen5—twice as fast as the 990 PRO SSD—making it the undisputed champion of SSDs on the market.

Every task, turbocharged
Random speed
Speed past productivity limits. With random read/write speeds up to 2,200K/2,600K IOPS⁴, enjoy fast game loads, seamless AI apps, and efficient multitasking. Virtually no lag, no limits—just nonstop performance.

Think fast, create faster.
Boost AI applications
With random read/write speeds of up to 2,200K/2,600K IOPS, the 9100 PRO with Heatsink SSD fuels seamless AI content creation, swift loads, and smooth gameplay. Work, play, and create at lightning speed.

Designed for compatibility, built for speed.
Compatibility
No barriers, just action. Team up with the 9100 PRO with Heatsink SSD on your compatible PC, laptop, or PlayStation® 5 and dive into top-notch performance with the newest PCIe 5.0 interfaces. Crush the competition and come out on top in any arena.

Stay cool, run fast.
Innovative Power & Thermal Control
Push limits, not temperatures. A 5nm controller boosts power efficiency up to 49% over the 990 PRO SSD, while advanced thermal control keeps performance smooth and reliable.

Slim build. Seamless fit.
Slim Design
The 9100 PRO with Heatsink SSD delivers top-tier speed and storage into a low profile as slim as 0.35", fitting compatible PCs, laptops, and PlayStation® 5—maximizing performance without sacrificing space or efficiency.

Break free from storage limits
Capacity
Expand your gaming horizons with up to 8TB of storage on the 9100 PRO with Heatsink. Enjoy vast space to grow your game library, save every title, and keep all your favorites without compromise. Unleash your full gaming potential—store, save, and conquer like never before.

Works like magic
Always Up-to-Date via Magician Software
It’s not hocus-pocus. Your 9100 PRO with Heatsink SSD performs like new with the always up-to-date Magician Software. Get seamless firmware updates, extra encryption and continual monitoring of your drive health—no magic wand required.

World's No. 1 Flash Memory Brand
Performance and reliability you can count on from the world's number one brand for flash memory since 2003.* All firmware and components are produced in-house, including our world-renowned DRAM and NAND, for quality you can trust.

Specifications

General Information

• Application : Client PCs, Game Consoles
• Capacity : 4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
• Form Factor : M.2 (2280)
• Interface : PCIe® 5.0 x4, NVMe™ 2.0
• Dimension (WxHxD) : 3.2 x 0.9 x 0.09 in
• Weight : 0.02 lbs
• Storage Memory : Samsung V-NAND TLC
• Controller : Samsung in-house Controller
• Cache Memory : Samsung 4GB Low Power DDR4X SDRAM
• Shipping Weight : 0.16 lbs
• Special Feature : TRIM Support
• Supported : S.M.A.R.T Support
• Supported : GC (Garbage Collection)
• Auto Garbage Collection Algorithm : Encryption Support
• AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
• WWN Support : Not supported
• Device Sleep Mode Support : Yes

Performance

• Sequential Read
• Up to 14,800 MB/s * Performance may vary based on system hardware & configuration
• Sequential Write
• Up to 13,400 MB/s * Performance may vary based on system hardware & configuration
• Random Read
• Up to 2,200,000 IOPS * Performance may vary based on system hardware & configuration
• Random Write
• Up to 2,600,000 IOPS * Performance may vary based on system hardware & configuration

Environment

• Average Power Consumption (system level)
• Average: Read 9.0 W / Write 8.2 W* Actual power consumption may vary depending on system hardware & configuration
• Power consumption (Idle)
• Typical 6.5 mW * Actual power consumption may vary depending on system hardware & configuration
• Power Consumption (Device Sleep)
• Typical 5.7 mW * Actual power consumption may vary depending on system hardware & configuration
• Allowable Voltage : 3.3 V ± 5 % Allowable voltage
• Reliability (MTBF) : 1.5 Million Hours Reliability (MTBF)
• Operating Temperature : 0 - 70 ℃ Operating Temperature
• Shock : 1,500 G & 0.5 ms (Half sine)

Accessories

• Installation Kit
• Not Available
• Software
• Management SW
• Magician Software for SSD management
